I. Technical Specification

 Power Supply

 DC 6V（1.5V AAAx4）

Test Mode

 Clamp CT, integration method

*Transmission Mode

 B type: 433Hz wireless transmission, transmission distance 30M

 Display Mode

 4 digital LCD display, backlight function, suitable for dim place

 LCD Size

 47mm×28.5mm

 Meter Size

 Detector: 84mm×255mm×39mm; Receiver: 78mm×165mm×42mm

 CT Size

 Ф48mm

 Sampling Rate

 2 times/second

 Measurement Range

 0mA～1200A (50/60Hz automatic)

 Max Resolution

 1mA

 Shift

 0mA～1200A full-automatic

 Test Accuracy (23℃±5℃，below80%RH)

 0mA～99.9A:    ±1%rdg±5dgt

 100A～599A:      ±1.5%rdg±5dgt

 600A～1200A:     ±2%rdg±5dgt

 Data Storage

 99 groups, in storage process "MEM" symbol display, "FULL" symbol flashes display indicate storage full

 PEAK Hold

(only for XZTY9000)

Automatically hold the peak test value. Press the PEAK button in normal test mode, and the PEAK light will be on, that is, the PEAK HOLD function will be enabled, and then press the PEAK key to cancel the function.

 Line Voltage

 Below 110kV current test , operate with insulation rods ( below 500kV can be customized ，only for XZTY9000B)

 Data Hold

 Press HOLD key to hold data in test mode, “HOLD” symbol display, press HOLD key once again cancel this function

 Data Access

 "MR" symbol display, can look up all storage data

 Overflow Display

 Exceed measure range overflow function: "OL A" symbol display

 *No Signal Indication

 When the receiver has not received transmit signal, dynamic display “no- -”symbol

 Auto Shut Down

 15 minutes after boot up, the meter shuts down automatically without any operation, to reduce battery consumption

 Battery Voltage

 When battery voltage is lower than 4.8V, low battery voltage “     ”symbol will display and remind to replace battery.

 Meter Weight

 Detector: 363g, Receiver: 272g, the meter total weight: 3.3 kg

 Working Environment

 -10℃~50℃；below 80%rh

 Store Environment

 -10℃~60℃；below 70%rh

 Interference

 No interference of 315MHz and 433MHz same frequency signals

 Insulation Rod Size

 4300mm

 Insulation Withstand Voltage

 AC110kV/rms（The telescopic insulation rod is fully opened between the two ends）
