Power Supply

DC 9V(Alkaline dry cell R14 1.5V*6PCS

Rated Voltage

AC 220V

Leakage Current Gears

3mA，5mA，7mA，10mA，15mA，20mA，30mA，35mA，50mA，100mA，125mA，150mA，175mA，250mA，275mA，300mA，375mA，500mA

Current Accuracy

±10%rgt±5dgt

Rotary Knob Gear

OFF; V; X1; X2;X3; Auto (6gears)

Test Mode

Manual:

X1（3mA，5mA，7mA，10mA，15mA，20mA）

X2（30mA，35mA，50mA，100mA，125mA，150mA）

X3（175mA，250mA，275mA，300mA，375mA，500mA）

Auto: 3mA~500mA

Leakage Initiating Time Range

0~999ms.

Leakage Initiating Time Accuracy

5%rgt±3%dgt

AC Voltage Range

0~600V

AC Voltage Accuracy

±2rgt%±5dgt

Phase Select

0°/ 180°

Data Hold

After testing finish, the interface will hold the test result automatic

Failure Information Indication

LCD display “999” over time indication, it is possible that the rated initiating current grade of tested is too small or the leakage protector is faulty.

Test Wire Length

1.5M

Display Mode

4-digital large LCD display, white screen backlight

Teter Dimension

215mm×178mm×83mm

Tester Weight

Host: 955g(with battery); Total weight: 2kg(include all accessories)

Battery Voltage

When the battery voltage lower than 7.4V, low battery voltage symbol“    ” display, and remind to replace the battery

Working Current

100mA Max

Working Temperature

-10℃-40℃, below 80%rh.

Storage Temperature

-10℃-60℃, below 70%rh.

Insulation Strength

≥100MΩ, AC 2kV/rms (between the shell and the screw).

Suitable Safety Standard

IEC1010-1, IEC1010-2-032, Pollution degree 2, CAT III(600V) IEC61326 (EMC standard).
